8 Mono-, 2 Stereokanäle
XLR Summenausgang
100mm Fader
3 Aux
3 Band EQ para. Mids

Spirit F1 is a rugged multi-purpose console capable of Digital quality (mic EIN -129dBU) mixing for live sound, recording, sub mixing and location sound applications. F1 is unique amongst small mixers at this price range in its use of 100mm faders - previously the sole reserve of large, professional consoles. These give greater control and flexibility at mixdown than standard 60mm designs.

F1 comes in 16/2 or 14/2 input versions with 8 or 6 mono channels avialable. These included Soundcraft's high quality UltraMic™ preamps giving 60dB of gain range and 22dB headroom, meaning that the F1 input stage can handle virtually any mic or line device. F1 includes 8 outputs (including aux's) as standard and 4 stereo inputs for keyboards, effects or stereo playback equipment. Mono inputs all have steep 100Hz (18dB per octave) High Pass Filters to eliminate low frequency rumble. There are inserts on every mono input for connecting signal processors as well as channel muting capability. F1 also includes an additional mono sum output for drum fill speakers, subwoofers or mono PAs.

F1 features the authentic British 3-band EQ with swept mid benefits from custom designed potentiometer laws which give greater control across carefully chosen frequencies. There are also 3 auxiliary sends with aux 2 pre/post switchable for monitoring or effects. The auxiliary section includes aux masters control and sole capabilities.

The F1 fits all of these features into a rugged, compact frame with integral carry handle which can be optionally rack-mounted into a 10U rackmount space.


Live Sound:
Bands, Small Venues, Schools, Conferences, Houses of Worship
Studio Recording:
Project/Small/Home Studios, MIDI Programming, Post-Production Submixing
Location Sound
